• How adaptation is done in HTML5:
    • Log in to HTML5.
    • Click on Adapt.
    • Edit Master Layout or Edit Page layout.
    • The adaptations done here will have effect on HTML5, Responsive UI and Silverlight.
    • Tickets work center view is an exception.



  • How adaptation is done for Tickets work center view for changes to replicate in Responsive UI:
    • Log in to HTML5 UI.
    • Add the parameter “&simulateRUI=true” next to “runtime” and hit Enter.
    • The URL should be “https://myxxxxxx.crm.ondemand.com/sap/public/ap/ui/repository/SAP_UI/HTML5/client.html?app.component=/SAP_UI_CT/Main/root.uiccwoc&rootWindow=X&redirectUrl=/sap/public/byd/runtime&simulateRUI=true“
    • Now go to Tickets work center view.
    • Do the Adaptations here.
  • How adaptation is done from Responsive UI:
    • Log in to Responsive UI.
    • Click on the User name from the top right corner.
    • Click on Open layout in HTML5 . This will actually launch the tablet floor plan.
    • Do the Adaptations here.
    • The adaptations done here will have effect on HTML5, Responsive UI and Silverlight. Note: There are few work centers which is an exception, example: Tickets work center view. For tickets work center view the adaptations done here will have effect only in Responsive UI not in HTML5.
    • There is another Exception for the Survey. Adaptations done for the Survey screen is applicable only for HTML5 UI. Responsive UI will not consider the adaptations done for Survey. This is a limitation.
  • How adaptation is done in Extended app for Tablets:
    • The adaptations done in HTML5 will reflect in Extended App for Tablets.
  • How adaptation is done in Extended app for Smart Phones:
    • The adaptations done in HTML5 will reflect in Extended App for Smart Phones.
    • In addition, adaptations can be done specific to Extended App for Smart Phones as below
    • Launch HTML5.
    • Click on Adapt.
    • Edit Smart Phone Layout.
    • The adaptations done here will reflect only for smart phones and not for tablets.
